Forklift Safety — Access Control

Operator Access Control System

RFID, biometric, and dual-authentication devices that prevent unauthorized equipment operation and enforce operator accountability.

Request Quote Download Datasheet

FRAC — RFID FBAC — Biometric FDAC — Dual Auth

The Problem

Unauthorized or untrained operators on forklifts and heavy machinery are a leading cause of workplace incidents.

Unauthorized operation — Operators access machines without proper certification or authorization, creating liability and safety risk.
Zero accountability — Without access logging, there's no record of who operated which machine and when. Incident investigation becomes guesswork.
Compliance gaps — Manual SOP checks and paper-based logs are inconsistent. Management cannot enforce real-time compliance across shifts.
Utilization blind spots — No data on actual machine hours, idle time, or operator attendance patterns for fleet optimization.

How It Works

Authenticate

Operator presents RFID card, fingerprint, or both at the mounted access unit before starting the machine.

Verify & Authorize

System checks operator credentials against authorized list. Only certified operators can start the equipment.

Enable Ignition

Machine ignition is released only after successful authentication. Unauthorized attempts are blocked and logged.

Record & Report

All access events are logged with timestamp, operator ID, and machine ID. Data feeds into fleet management dashboards.

Key Features

Three Authentication Modes

RFID contactless card (FRAC), capacitive fingerprint (FBAC), or dual RFID + biometric (FDAC).

Ignition Interlock

Machine cannot start without successful operator authentication. Physically integrated with ignition circuit.

Seatbelt Integration

Can be combined with seatbelt interlock — machine requires both authorized operator and seatbelt fastened.

Offline Data Logging

Stores access events locally when network is unavailable. Syncs automatically when connection restores.

Hour Meter Reading

Tracks actual machine operating hours per operator. Feeds into maintenance scheduling and utilization reports.

Fleet Management Ready

Integrates with cloud dashboard for attendance management, GPS tracking, geo-fencing, and automated reporting.

Technical Specifications

Data from product datasheet. Three models available.

Parameter	Value
Operating Voltage	12–160V DC
Power Consumption	10W
Enclosure Material	ABS
IP Rating	IP65
Dimensions	200 × 120 × 60 mm
Authentication — FRAC	RFID contactless card
Authentication — FBAC	Capacitive fingerprint sensor
Authentication — FDAC	Dual — RFID + Fingerprint
Optional: Data Logging	Offline data logging
Optional: Hour Meter	Yes — per operator tracking
Applications	Forklifts, Trucks, Cars, Buses, Mining Trucks

System Integrations

Seatbelt Interlock Crash / Shock Sensor Collision Avoidance System Fleet Management — Attendance GPS Tracking & Geo-fencing Speed Limiting System

Customized solutions with additional features available on request.

Applications

Warehouses

Restrict forklift operation to trained, authorized personnel per shift.

Manufacturing

Enforce machine-specific operator certifications across shop floor equipment.

Ports & Yards

Control access to heavy earth-moving machinery and container handlers.

Mining

IP65-rated units for HEMM fleets in harsh, dusty environments.

Fleet Operators

Bus and truck fleet driver access control with attendance logging.

Installation & Integration

Retrofit Ready

Mounts directly on existing forklifts and MHE without structural modification. Standard bolt-on installation.

Power Requirements

Wide input range: 12–160V DC, 10W. Compatible with electric forklifts, diesel equipment, and battery-powered vehicles.

Ignition Integration

Wires into the machine's ignition circuit. No PLC modification required. Works with relay-based and electronic ignition systems.

System Expansion

Plug-in integration with seatbelt interlocks, speed limiters, crash sensors, and cloud-connected fleet management modules.
