Real-time proximity detection and voice alerts for loading dock safety. 8-meter sensing range. Chain interlock and door integration.
Loading docks are high-risk areas where vehicles back into positions while personnel work nearby on platforms. Without advance warning, dock workers have no time to react when vehicles approach.
Proximity sensors detect vehicles approaching the loading dock within the 8-meter range threshold with high sensitivity.
System continuously calculates real-time distance between vehicle and dock. Configurable distance zones trigger different alert levels.
Progressive voice announcements and audio alerts warn personnel as vehicle approaches. Alerts increase in urgency based on proximity.
System integrates with chain interlocks and automated doors to restrict access when vehicles are present and detected.
Adjustable detection distance from 1 to 8 meters. Customize for specific loading dock geometries and operational requirements.
Clear, pre-recorded voice alerts in multiple languages. Customizable messages for different dock zones and situations.
Intuitive web interface for system setup and customization. No technical expertise required for parameter adjustment.
Seamless integration with chain interlock systems. Automatic barrier engagement when vehicles detected at dock.
Controls automated sliding and roll-up doors. Prevents personnel entry during vehicle dock operations automatically.
Weather-sealed enclosures rated for harsh environments. Operates reliably in rain, snow, and extreme temperatures.
Data from product datasheet. Two configurations available.
| Parameter | Value |
|---|---|
| Operating Voltage | 12VDC |
| Maximum Current | 500mA max |
| Power Supply | Regulated 12VDC PSU required |
| Sensing Distance | 8m (configurable 1-8m) |
| Sensor Type | Proximity/Ultrasonic |
| Detection Accuracy | ±0.5m at 8m range |
| Speaker Power | 15W-25W |
| Audio Output | Pre-recorded & customizable |
| SPL Output | 85-95dB at 1m |
| Operating Temperature | -10°C to +50°C |
| IP Rating | IP65 (sealed/weatherproof) |
| Installation | Indoor/Outdoor |
Can be integrated with all other Controlytics facility safety solutions. Customized configurations available on request.
Active vehicle detection with automatic personnel barriers and progressive voice warnings at loading platforms.
High-volume vehicle traffic with multiple loading zones. Automatic alerts prevent dock personnel injuries from vehicle collisions.
Vehicle receiving and shipping areas with staff working dock platforms. Real-time proximity warnings and distance awareness.
Material receiving docks and vehicle access areas at production facilities with pedestrian activity and safety requirements.
Temperature-resistant design for refrigerated receiving and shipping areas with vehicle traffic and personnel safety.
We assess the loading dock layout and determine optimal sensor placement for maximum detection coverage and accuracy.
Mount proximity sensors and speaker units at dock entrance. 12VDC power supply connection. Standard wiring, minimal disruption.
Access the web-based interface to configure detection range, voice messages, and barrier integration parameters easily.
Comprehensive system testing and staff training on alert responses. Performance validation before full operational deployment.
