Vehicle-to-vehicle collision avoidance with UWB ranging. 360° coverage, configurable zones, auto-braking. Choose V2V-CAS for alerts or V2V-CACS for automated braking control.
Blind spot crashes occur when equipment intersections have limited visibility. Multiple MHE in confined spaces, low-light operations, and high-speed movements create dangerous collisions.
Four high-precision UWB ranging sensors on each vehicle detect nearby equipment continuously with omnidirectional coverage.
V2V wireless communication exchanges position data; DPU calculates relative distance and closing speed in real-time.
V2V-CAS triggers audio/visual alerts; V2V-CACS applies automatic braking and speed reduction for active collision prevention.
All proximity events and control actions are recorded for safety analysis and compliance reporting across your fleet.
Four high-precision ranging sensors provide complete omnidirectional collision detection around the vehicle.
Configurable detection zones with different alert/control thresholds for operational safety flexibility.
V2V-CAS (alert-only) or V2V-CACS (auto-brake) systems based on your safety requirements and operational needs.
Detects approaching vehicles from near-field to 30 meters for advanced warning and rapid response capability.
Automatic braking and low-speed mode for V2V-CACS prevents high-speed collisions in critical situations.
Proven operation in mining, ports, construction with extreme conditions and guaranteed high reliability.
Data from product datasheet. Two system configurations available.
| Parameter | Value |
|---|---|
| System Type | Vehicle-to-Vehicle Collision Avoidance |
| Detection Technology | UWB Wireless Ranging |
| Communication Method | V2V Wireless Position Exchange |
| Coverage Pattern | 360° (4 High-Precision Sensors) |
| Detection Range | 0.2 - 30 meters |
| System Models | V2V-CAS (Alert) | V2V-CACS (Control + Auto-Brake) |
| Operating Voltage | 12 - 160V DC |
| Power Consumption | 10W |
| DPU Housing | ABS, IP65 Rated |
| DPU Dimensions | 80 x 120 x 60 mm |
| Alert Types (V2V-CAS) | Buzzer, Hooter, CVAD, Beacon, LED Flash, Rotating Beacon |
| Applications | Forklifts, Trucks, Cars, Buses, Mining Trucks |
Can be integrated with all other Controlytics MHE solutions. Customized configurations available on request.
Prevent collisions between forklifts and MHE in high-density storage and retrieval operations.
Critical for large-scale mining with massive equipment and confined haul roads in complex terrain.
Container handling with heavy equipment and complex traffic patterns at container terminals.
Factory floors with multiple equipment and complex material flow patterns requiring collision prevention.
Mobile equipment operations with high-speed vehicles and multiple concurrent on-site activities.
Install Data Processing Unit in secure enclosure on vehicle interior for protected operation.
Mount four UWB ranging sensors on equipment (front, rear, left, right) for 360° coverage and detection.
Wire DPU to vehicle 12-160V DC electrical system (10W typical). Works with all vehicle architectures.
Integrate with Seatbelt Interlock, Speed Limiting, Proximity Detection, Fleet Management, and GPS for comprehensive safety ecosystem.
