Warehouse Safety — Traffic Management

Automatic Pedestrian & Vehicle Detection System

Automatic detection of pedestrians and vehicles at junctions and crosswalks. Integrates with traffic lights, boom barriers, and alert systems for seamless traffic flow.

Request Demo Download Datasheet

Sensor-Based Detection Full Traffic Control

The Problem

Uncontrolled pedestrian and vehicle movements at facility junctions cause frequent accidents and inefficient traffic flow. Manual crossing management is unreliable and introduces human error.

Junction collisions — Uncontrolled pedestrian and vehicle movements at intersections cause frequent severe accidents. Without detection, collisions are inevitable at high-traffic areas.
Manual crossing management — Reliance on human operators for traffic control is unreliable, slow, and introduces human error. Guards cannot monitor multiple crossing points simultaneously.
No automatic detection — Without real-time sensing, crossing management cannot respond dynamically to pedestrian and vehicle presence. Static signals fail during variable demand periods.
Pedestrian non-compliance — Pedestrians ignore manual signals or cross unsafely; vehicles proceed without confirmation of clear zones. No enforcement mechanism exists.

How It Works

Auto-Detect Movement

Sensors detect pedestrians approaching crosswalks and vehicles at junctions in real-time.

Signal Control

System automatically activates appropriate traffic lights, red/green signals, and boom barriers.

Barrier Management

Boom barriers lower automatically to halt vehicle movement when pedestrians are crossing.

Event Logging

All detection events and control actions are recorded for compliance and analysis.

Key Features

Auto Detection

Sensor-based automatic pedestrian and vehicle movement detection at all times.

PELICON Switches

Wired, wireless, or solar-powered pedestrian crossing switches integrated with system.

Boom Barrier Integration

Direct integration with motorized boom barriers for automatic vehicle halt.

Traffic Lights

200mm and 300mm traffic light modules (24V DC, 30W) with automated control.

Solar Option

Optional solar-powered operation for areas without reliable mains power.

Control Panel

230VAC/110VAC 6A control panel with LOTO isolator and protection circuits.

Technical Specifications

Data from product datasheet. Complete system configuration details.

Parameter	Value
System Type	Automatic Pedestrian & Vehicle Detection
Detection Technology	Sensor-Based (IR, Microwave, or Optical)
Pedestrian Crosswalk Detection	Automatic Movement Recognition
Vehicle Detection	Junction & Approach Sensors
Control Panel Power	230VAC/110VAC 6A
Traffic Light Voltage	24V DC
Traffic Light Power	30W per Module
Traffic Light Sizes	200mm & 300mm Diameter
PELICON Switches	Wired, Wireless, or Solar
Boom Barrier Integration	Motorized Boom with Safety Interlocks
Safety Features	LOTO Isolator, Short Circuit Protection, Overload Protection, Double Earthing
Data Logging	Event Recording with Timestamps

System Integrations

Traffic Management Barrier Control Signal Systems Safety Monitoring Data Logging

Can be integrated with facility management and security systems. Customized configurations available on request.

Applications

Factory Gates

Control vehicle entry and exit with pedestrian crossings at main and secondary access points.

Crosswalks

Automated pedestrian crossing management with automatic signal control.

Loading Areas

Separate pedestrian and vehicle traffic zones with automatic detection and barriers.

Parking Lots

Automated entry/exit gates with pedestrian detection and vehicle movement control.

Industrial Campuses

Multi-junction management across large facilities with centralized monitoring and control.

Installation & Integration

Install Control Panel

Mount 230VAC/110VAC 6A control panel in protected enclosure at junction/crossing point.

Mount Detection Sensors

Place sensors at pedestrian crosswalk approaches and vehicle junction points for comprehensive coverage.

Install Traffic Lights

Mount 200mm or 300mm traffic light modules at appropriate heights (24V DC supply) for visibility.

Connect Boom Barriers

Wire motorized boom barriers to control panel with safety interlocks for vehicle control.
