Pedestrian Warning & Alert System for Cranes

Active UWB-based tracking. Real-time under-crane positioning. MPAS alert and MPCS control models for overhead and mobile cranes.

Request Demo Download Datasheet

MPAS Alert MPCS Control

The Problem

Overhead crane operations create massive blind spots directly below the equipment. Dropped loads and unsafe proximity to personnel in hazard zones cause fatal incidents.

Massive blind spots — Crane operators cannot see directly below. Large overhead areas remain invisible even with mirrors and cameras installed. No visibility of ground personnel.
Dropped load zones — Critical areas below crane paths vulnerable to dropped loads. No real-time indication if personnel are in danger zones. Manual spotters are unreliable.
Pedestrians beneath cranes — Personnel working under crane operation areas face serious risk without system protection or awareness. High-consequence incident zones.
No real-time tracking — No system to track personnel position relative to crane load. Operators unaware of critical proximity situations. Static safety zones are insufficient.

How It Works

Personnel Tags

Personnel wear lightweight UWB tags. Tags transmit unique identification and location signals continuously during operation.

UWB Detection

UWB receiver nodes mounted on crane detect tag proximity. Real-time positioning accurate to sub-meter levels. 360° coverage area.

Alert or Control

MPAS model triggers audible alerts when personnel too close. MPCS model automatically restricts crane movement when danger detected.

Continuous Tracking

Complete position tracking under crane path. Operators see real-time personnel location dashboard. Safety audit logs maintain compliance.

Key Features

360° Under-Crane Coverage

Comprehensive detection across entire area beneath crane operation. Omnidirectional monitoring with no blind spots.

Tag-Based Tracking

Personnel wear compact UWB tags. Real-time positioning with sub-meter accuracy. Unique ID tracking for individual personnel.

MPAS/MPCS Models

MPAS for alert-only deployment. MPCS for automatic crane control. Choose model based on operational requirements.

0.2-30m Range

Extended range from near-field (0.2m) to 30-meter coverage. Covers all typical overhead crane operational areas.

Harsh Environment Rated

IP65 rated components. Operates in extreme temperatures, moisture, dust, and electrical noise of industrial environments.

Charging Station for Tags

Integrated charging dock for personnel tags. Quick-charge capability for shift operations. Long battery life per charge.

Technical Specifications

Data from product datasheet. Complete system specifications.

Parameter	Value
Technology	Ultra-Wideband (UWB) Positioning
Coverage Pattern	360° Under-Crane Monitoring
Detection Range	0.2m to 30m
Positioning Accuracy	Sub-meter accuracy
Operating Voltage	12-160V DC
Power Consumption	10W maximum
Receiver Node Housing	High-strength ABS, IP65 Rated
Node Dimensions	Standard industrial form factor
Wearable Tags	Battery-powered UWB transmitters
System Models	MPAS (Alert) \| MPCS (Control)
Alert Types	Audio & Visual Alerts, Brake Signal
Charging Station	Included, Quick-charge capable

System Integrations

Overhead Cranes Mobile Cranes Crane Control Systems Safety Management Compliance Logging

Can be integrated with crane control systems for automatic load hold. Customized configurations available on request.

Applications

Steel Plants

Heavy EOT cranes with overhead bridge operation. Personnel on shop floor under active crane paths. Critical safety zone protection.

Ports & Terminals

Container handling with mobile and gantry cranes. Personnel on dock areas beneath active load movement. High-speed operation zones.

Shipyards

Overhead cranes for ship assembly and component handling. Multiple personnel under active crane operation simultaneously.

Heavy Manufacturing

Overhead bridge cranes with large load movement. Multiple work stations beneath crane operation envelope. Regular personnel activity.

Mining Operations

Overhead cranes in mine processing facilities. Personnel in multiple hazard zones beneath active crane movement.

Installation & Integration

Hazard Zone Mapping

Identify areas beneath crane operation where personnel work. Define safety zones and alert thresholds based on crane specifications.

Hardware Installation

Mount UWB receiver nodes on crane structure or fixed points. Install DPU control unit. Connect to crane control system for MPCS integration.

Personnel Tagging

Deploy UWB tags to personnel working under crane zones. Set up charging station for tag battery management. Configure personnel ID mapping.

Testing & Certification

Full system testing with simulated crane operation. Verify detection accuracy and alert response. Safety certification and operator training.
